N-EUPEX and N-EUPEX DS pin couplings connect machines. They compensate for shaft misalignment, generating only low restorative forces.
The torque is conducted through elastomer flexibles, so the coupling has typically flexible rubber properties.
N-EUPEX couplings are overload-holding. By contrast, the N-EUPEX DS series is designed so that overload or advanced wear causes irreparable damage to the elastomer flexibles. The metal parts of N-EUPEX DS couplings can then rotate freely against one another without contact.
Coupling suitable for use in potentially explosive atmospheres.
Complies with the current ATEX Directive for:
II 2G Ex h IIC T6 ... T4 Gb X
II 2D Ex h IIIC T85 °C ... 110 °C Db X
I M2 Ex h Mb X
